Operating Conditions:

• nominal pressure: 700 bar/15°C
  • maximum allowable working pressure: 875 bar/85°C
  • proof pressure: 1050 bar
  • burst pressure: 1750 bar
• temperature pressure relief device: 110 ±5°C
• excess flow valve activation: 3 g/s bei 20 bar
• operation temperature: -40°C - +85°C
• fueling: max 60 g/s
• defueling: 0-3 g/s (p>35 bar), 0-2g/s (p>20 bar)
• supply voltage: 12 -4/+5 V
• peak current: 0.5 A (5 sec)
• hold current: 0.15 A

weight ca. 640g
dimensions: 125 x 69 x 61 mm
Standard high pressure connection: 2 VossVL40 MM06 sockets (metallic sealing)
Other connection systems possible on request
